Price on RFP / Quotation
In Stock • Authorized Partner Supply
Technical Specifications
Official manufacturer parameters • Verified by Samari IT Solution| General | |
|---|---|
| Camera | IPC2322LBR3-SP-D |
| Sensor | 1/2.7", 2.0 megapixel, progressive scan, CMOS |
| Lens | 2.8~12 mm, manual zoom lens |
| DORI Distance | Lens |
| 2.8mm | 42 |
| 12mm | 180 |
| Angle of View (H) | 112.7??~28.1?? |
| Angle of View (V) | 60.1??~15.4?? |
| Angle of View (O) | 146.5??~33.2?? |
| Adjustment angle | Pan: 0??~360?? |
| Shutter | Auto/Manual, 1~1/100000 s |
| Minimum Illumination | Colour: 0.01 Lux (F1.6, AGC ON) 0 Lux with IR on |
| Digital noise reduction | 2D/3D DNR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| S/N | >52dB |
| IR Range | Up to 30m (98 ft) IR range |
| WDR | DWDR |
| Video Compression | Ultra 265,H.265, H.264, MJPEG |
| H.264 code profile | Baseline profile, Main Profile, High Profile |
| Frame Rate | Main Stream:1080P (1920??1080): Max. 30 fps; Sub Stream:720P (1280??720): Max. 30 fps; Third Stream: D1(704??576): Max. 30 fps |
| HLC | Supported |
| BLC | Supported |
| OSD | Up to 4 OSDs |
| Privacy Mask | Up to 8 areas |
| ROI | Up to 2 areas |
| Motion Detection | Up to 4 areas |
| Protocols | IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP, RTP,RTSP,RTCP,DNS,DDNS,NTP,FTP,UPnP,HTTP,HTTPS,SMTP, SSL |
| Compatible Integration | ONVIF(Profile S, Profile G), API |
| Network | 1 RJ45 100M Base-TX Ethernet |
| Edge Storage | MicroSD, up to 128GB |
| Power | 12 V DC??25%, PoE (IEEE802.3 af) |
| Dimensions (L ?? W ?? H) | 253.4??86??71.7mm(9.98?????3.4?????2.8???) |
| Weight | 1kg (2.2lb) |
| Working Environment | -30??C ~ +60??C (-22??F ~ 140??F), Humidity :10%~90% RH(non-condensing) |
| Ingress Protection | IP67 |
| Vandal Resistant | IK10 |
