UNV NTA-PET-4T-W-IN 4-Port Fast Ethernet Fiber Transceiver
4-Port 10/100M Fiber Optic Media Converter / Transceiver (Wall Mount)
- 10/100M auto-negotiation Ethernet to Optical Fiber conversion
- Wall mount enterprise design with robust metal casing
- Surge protection and lightning immunity for industrial networks
- Low latency transmission up to 20km over single-mode fiber
Price on RFP / Quotation
In Stock • Authorized Partner Supply
Technical Specifications
Official manufacturer parameters • Verified by Samari IT Solution| Hardware Specification | |
|---|---|
| Ports Type | 1x 100M PoE PD port3x 100M PoE PSE ports |
| Switching capacity | 0.8Gbps |
| Forwarding performance | 0.5952Mpps |
| MAC | 2K |
| PoE Standard | IEEE 802.3af, IEEE 802.3 at |
| Max.Power | Mainboard Power Consumption: <1W |
| Power Supply | PoE Input: 44V to 57VMax. input power: 30WMax. output power: 25W |
| Working Mode | DIP Switch OFF：Link extension mode disabled. DIP Switch ON：Link extension mode enabled，PoE and data distance extended to 250m，rate reduced to 10Mbps |
| Storage Temperature | -40~70°C |
| Operating Temperature | 0~40°C |
| Indicator | PoE IN indicator, PoE1 indicator, PoE2 indicator, PoE3 indicator |
| Waterproof | IP65 |
| Packing | |
| Once packing dimension | Product Dimensions: 146.6*97*34.5mmPackage Dimensions: 102*152*36mmNet Weight: 0.15kgGross Weight: 0.17kg |
| Twice packing dimension | Carton Dimensions: 375x335x220mmQuantity per Carton: 40 unitsCarton Weight:8.04kg |
